Planar DirectLight Slim Series
Indoor LED Video Wall
Ultra-thin, narrow MicroLED displays for tight curves and space-constrained installations
Planar® DirectLight® Slim Series indoor fine pixel pitch MicroLED displays deliver vivid visualization in an ultra-thin, narrow width form factor that facilitates a variety of deployment applications. The slim shape enables both tightly curved and flat video walls with minimal depth and front serviceability. This video wall offers high bandwidth and remote power for mission-critical applications requiring 24x7 operation. The DirectLight Slim Series is manufactured in Europe, ensuring quick lead times, stable pricing and shorter shipping distances.
- 0.9, 1.2, 1.5, & 1.8mm pixel pitches
- Featuring MicroLED technology
- Innovative narrow cabinet design for curved video walls with minimal color shift
- Ultra-thin profile of less than 2” (29.5mm) with full front serviceability
- EverCare Lifetime Warranty
- Made in Europe
Highlights
Uniquely Designed for Unique Spaces
Designed with a narrow form factor and an ultra-slim profile of less than 2" deep, Planar DirectLight Slim Series cabinets enable versatile applications such as curves and column wraps, while their compact design is ideal for maximizing space in constrained environments.
Tight Curves
The narrow cabinet design enables faceted, concave curved video walls with radii as small as 3mm and 4mm to surround viewers with content. Curved video walls support applications such as simulation and training, research, broadcast, virtual production, extended reality, and hospitality.
Reliable Off-Board Power
The Planar® Remote Power Supply (RPS) removes heat, depth, noise, weight, service points, and power outlets from the video wall and into a rack room. Featuring n+1 redundant, hot-swappable power modules, the Planar RPS is available in 110V and 220V and has a low-power standby mode when not in use 24x7.
Easy Access
Front installation and service reduces the overall video wall footprint and service space required behind the wall, making it easier to fit into more spaces than other LED video wall solutions.
High Bandwidth
With 5x the bandwidth of competitive solutions, the displays reduce total cost of ownership with fewer cabinets, cables, and internal components such as receivers and power supplies.
Flexible Control
The Planar® WallDirector™ Video Controller offers robust standardized processing, while compatibility with Brompton and Colorlight gives customers the freedom to choose the ideal solution for their application's unique requirements.
Lifetime Protection
The Planar DirectLight Slim Series is protected by the EverCare™ Lifetime Limited Warranty, which covers the entire display, from the sub-pixels to the video controller, for as long as it is used in a fixed location.
Made in Europe
Thanks to our state-of-the-art production facility in the heart of Europe, Leyard Europe can guarantee stable prices, short delivery times of just a few weeks, and high quality standards for the Planar DirectLight Slim Series.
Add-Ons & Accessories
Planar WallDirector Cloud
Remotely monitor and maintain your display fleet with Planar® WallDirector™ Cloud, a secure, web-based dashboard for diagnostics, commands, troubleshooting, health monitoring and support tickets.
Add Durability
Planar® ERO-LED™ (Extended Ruggedness and Optics™) proprietary protective coating provides durability in high-traffic and interactive environments. It offers a matte finish that maintains the visual performance of the video wall.
Product Images
Specifications
| DLSlim 0.9M20 | DLSlim 1.2M20 | DLSlim 1.5M20 | DLSlim 1.8M20 | |
|---|---|---|---|---|
| Pixel Pitch (mm) | 0.945mm | 1.26 x 1.25mm | 1.575mm | 1.89mm |
| Cabinet Resolution (WxH) | 320 x 720 | 240 x 544 | 192 x 432 | 160 x 360 |
| Pixel Density (pixel/m²) | 1119789 per m² | 634547 per m² | 403124 per m² | 279947 per m² |
| Brightness, max. (cd/m²) | 1600 nits | 1600 nits | 1600 nits | 1600 nits |
| Refresh Rate (Hz) | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| Color Temperature (K) | 3000 - 10000 adjustable | 3000 - 10000 adjustable | 3000 - 10000 adjustable | 3000 - 10000 adjustable |
| Viewing Angle, Horizontal (°) | >170° | >170° | >170° | >170° |
| Viewing Angle, Vertical (°) | >170° | >170° | >170° | >170° |
| Cabinet Size (WxHxD) | 302.4 x 680.4 x 34mm (11.91 x 26.79 x 1.34in) | 302.4 x 680.4 x 34mm (11.91 x 26.79 x 1.34in) | 302.4 x 680.4 x 34mm (11.91 x 26.79 x 1.34in) | 302.4 x 680.4 x 34mm (11.91 x 26.79 x 1.34in) |
| Cabinet Area (m²) | 0.2058 | 0.2058 | 0.2058 | 0.2058 |
| Module Composition (WxH) | 1x4 | 1x4 | 1x4 | 1x4 |
| Module Resolution (WxH) | 320 x 180 | 240 x 136 | 192 x 108 | 160 x 90 |
| Module Size (mm) (WxHxD) | 302.4 × 170.1mm (11.91 x 6.7in) | 302.4 × 170.1mm (11.91 x 6.7in) | 302.4 × 170.1mm (11.91 x 6.7in) | 302.4 × 170.1mm (11.91 x 6.7in) |
| Cabinet Weight (kg) | 6.94kg (15.3lb) | 6.94kg (15.3lb) | 6.94kg (15.3lb) | 6.94kg (15.3lb) |
| Lifetime (hrs) | 100000 hours | 100000 hours | 100000 hours | 100000 hours |
| Power Consumption, max. (W/m²) | 145 W | 145 W | 145 W | 145 W |
| Operation Temperature (°C) | -20° to 40° C | -4° to 104° F | -20° to 40° C | -4° to 104° F | -20° to 40° C | -4° to 104° F | -20° to 40° C | -4° to 104° F |
| Operation Humidity (RH) | 10-80% RH, non-condensing | 10-80% RH, non-condensing | 10-80% RH, non-condensing | 10-80% RH, non-condensing |
| Storage Temperature (°C) | -40° to 60° C | -40° to 140° F | -40° to 60° C | -40° to 140° F | -40° to 60° C | -40° to 140° F | -40° to 60° C | -40° to 140° F |
| Storage Humidity (RH) | 10-85% RH, non-condensing | 10-85% RH, non-condensing | 10-85% RH, non-condensing | 10-85% RH, non-condensing |
| LED Type | MicroLED FlipChip | MicroLED FlipChip | MicroLED FlipChip | MicroLED FlipChip |
| Contrast Ratio | 10000:1 | 10000:1 | 10000:1 | 10000:1 |
| Brightness Uniformity | ≥97% | ≥97% | ≥97% | ≥97% |
| Color Uniformity | ≥97% | ≥97% | ≥97% | ≥97% |
| Color Gamut | >93% DCI-P3 | >93% DCI-P3 | >93% DCI-P3 | >93% DCI-P3 |
| Cabinet Diagonal | 744.5mm | 744.5mm | 744.5mm | 744.5mm |
| LEDs per Module | 57600 | 32640 | 20736 | 14400 |
| HDR (High Dynamic Range) | Yes | Yes | Yes | Yes |
| Service Access | Front Access, module removal. All internal electronics accessible | Front Access, module removal. All internal electronics accessible | Front Access, module removal. All internal electronics accessible | Front Access, module removal. All internal electronics accessible |
| Installation | Standard Flat Wall | Forward Tilt: up to 10° | 90° exterior corners | Concave faceted curve | Standard Flat Wall | Forward Tilt: up to 10° | 90° exterior corners | Concave faceted curve | Standard Flat Wall | Forward Tilt: up to 10° | 90° exterior corners | Concave faceted curve | Standard Flat Wall | Forward Tilt: up to 10° | 90° exterior corners | Concave faceted curve |
| Video Controller | Planar® WallDirector and ColorLight Controllers | Planar® WallDirector and ColorLight Controllers | Planar® WallDirector and ColorLight Controllers | Planar® WallDirector and ColorLight Controllers |
| Acoustic Noise | <30dBA, Fanless operation | <30dBA, Fanless operation | <30dBA, Fanless operation | <30dBA, Fanless operation |
| TAA Compliant | Yes | Yes | Yes | Yes |
| ADA Compliant | Yes | Yes | Yes | Yes |
| Line Voltage | 100~240V AC, 50/60Hz | 100~240V AC, 50/60Hz | 100~240V AC, 50/60Hz | 100~240V AC, 50/60Hz |
| Approvals | NRTL UL 60950-1 TUV Rheinland, FCC Class A, CE EN60950-1, EN 55032 Class A and EN55024, WEEE, CISPR 32/2015 | NRTL UL 60950-1 TUV Rheinland, FCC Class A, CE EN60950-1, EN 55032 Class A and EN55024, WEEE, CISPR 32/2015 | NRTL UL 60950-1 TUV Rheinland, FCC Class A, CE EN60950-1, EN 55032 Class A and EN55024, WEEE, CISPR 32/2015 | NRTL UL 60950-1 TUV Rheinland, FCC Class A, CE EN60950-1, EN 55032 Class A and EN55024, WEEE, CISPR 32/2015 |
| Warranty | EverCare Limited Lifetime Warranty | EverCare Limited Lifetime Warranty | EverCare Limited Lifetime Warranty | EverCare Limited Lifetime Warranty |
| Download Specs | Download Specs | Download Specs | Download Specs |
Show all specifications
